micropultrusion

Goodwinds Composites manufactures high quality, small diameter carbon rods through a method we call micro pultrusion.

Micro pultruded rods are made from carbon fiber tow drawn through a resin bath and a series of dies and ovens to create a continuous rod of a specified diameter

We manufacture and sell micro pultruded carbon in 48″ pieces on our Solid Round Carbon Rods page as well as produce custom sizes and continuous lengths rolled on a reel.

Micro pultruded carbon rods are:

  • Between .019″ and .125″ in diameter
  • Made with a Fiber Volume Fraction (FvF) of 65% – 70%
  • Have a low tooling cost for custom orders
  • Have low minimum orders
  • Have a quick turnaround time
  • Can be coiled continuously or cut to spec

Call to talk to us today about micro pultruded rods at 206-632-6151.

pultrusion diagram
micropultrusion
Product #Name
Length
O.D.
Weight
Each6+12+24+48+Qty

CS020048

.020" x 48" Solid Round Carbon
48"
.020"
0.0007
$5.51$4.94$4.59$4.25$4.02

CS030048

.030" x 48" Solid Round Carbon
48"
.030"
0.0016
$5.74$5.17$4.82$4.48$4.13

CS040048

.040" x 48" Solid Round Carbon
48"
.040"
0.003
$5.74$5.17$4.82$4.48$4.13

CS050048

.050" x 48" Solid Round Carbon
48"
.050"
0.0059
$5.74$5.17$4.82$4.48$4.13

CS062048

.062" x 48" Solid Round Carbon
48"
.062"
0.0086
$6.09$5.40$5.05$4.71$4.36

CS070048

.070" x 48" Solid Round Carbon
48"
.070"
0.0103
$6.09$5.40$5.05$4.71$4.36

CS080048

.080" x 48" Solid Round Carbon
48"
.080"
0.0134
$6.09$5.40$5.05$4.71$4.36

CS098048

.098" x 48" Solid Round Carbon
48"
.098"
0.0206
$8.96$7.93$7.35$6.89$6.43

CS118048

.118" x 48" Solid Round Carbon
48"
.118"
0.0298
$9.19$8.16$7.58$7.01$6.67

CS125048

.125" x 48" Solid Round Carbon
48"
.125"
0.0341
$9.21$8.17$7.59$7.02$6.68

CS156048

.156" x 48" Solid Round Carbon
48"
.156"
0.0523
$10.91$9.65$8.96$8.38$7.81
